The Exidor 2000/4F floor pivot uses the same class leading bearing technology as the floor spring and is used in applications where there is no requirement for closing a door, and where using hinges is difficult because the door is heavy or a double action is required. The 2000/4F can carry a door up to 400KG whilst having a very small footprint, and only has a recess below the floor surface of 15mm.

The range is compatible with all Exidor floor spring strap systems and top centres, which must be ordered separately, if required.

Different height spindle extensions between 5mm and 50mm are available, but these must be ordered with the pivot as they cannot be changed on site.

Contents : Floor pivot with standard 5mm spindle
Compatible with : All Exidor floor spring accessories
CE Marked : No
Certifire : Yes
Guarantee : 10 year replacement only against manufacturing faults and defects in normal use
